Bobcat T595

Description

The Bobcat® T595 compact track loader has the highest horsepower and Rated Operating Capacity (ROC) in the popular 500 frame size. This vertical path loader provides recognizable power in digging and pushing applications. Engine Specifications Emissions Tier (EPA): Tier 4 Engine Cooling: Liquid Engine Fuel: Diesel Horsepower: 74 hp (55.2 kW) Turbocharged Engine: Optional Performance Specifications Rated Operating Capacity (SAE): 2,200 lb. (998 kg) Operating Capacity (50% of Tip): 3142 lb. (1425 kg) Tipping Load: 6285 lb. (2851 kg) Operating Weight: 8055 lb. (3654 kg) Travel Speed: 7.1 mph (11.4 km/h) Travel Speed (2-speed option): 10.4 mph (16.7 km/h) Ground Pressure (Rubber): 5.1 psi (0.35 bar) Capacities Fuel Tank: 36.5 gal. (138.2 L) Hydraulic System Specifications System Relief @ Quick Couplers: 3,500 psi (241.32 bar) Auxiliary Std Flow: 17.1 gal./min (64.7 l/min) Auxiliary High Flow: 26.7 gal./min (101.1 l/min) Dimensions Length: 133 in. (3378 mm) Length without Attachment: 104.6 in. (2657 mm) Length with Standard Bucket: 133 in. (3378 mm) Width: 67.1 in. (1704 mm) Width (with bucket): 68 in. (1727 mm) Height: 77.8 in. (1976 mm) Height with Operator Cab: 77.8 in. (1976 mm) Height to Bucket Hinge Pin: 119 in. (3023 mm) Reach @ Maximum Height: 34.9 in. (886 mm) Turning Radius: 80 in. (2032 mm) Length of track on ground: 54.1 in. (1374 mm) Track Width: 12.6 in. (320 mm) Track Width - Optional: 15.8 in. (401 mm) Features Joystick Control: Optional Air Conditioning: Optional
