2020 Virnig HSBP144

Description

Snow Blade/Pusher-V60-Hyd Wings-Bobcat 7 pin-SSL Virnig HSBP144 Snow Pusher (2020) – Specs Model: HSBP144 Series: Virnig V60 Hydraulic Snow Blade/Pusher Type: Hydraulic snow blade with dual wing system Application: Skid steer / compact track loader snow removal Dimensions Overall width (straight): 148.5 in Width at full angle (both wings open): 131.0 in Width at full angle (one wing open): 107.0 in Width at full scoop: 120.5 in Main moldboard width: 86.0 in Overall height: 31.0 in Overall depth (straight): 39.5 in Weight Operating / approximate weight: 1,650 lbs Hydraulics Cylinder bore: 2.0 in Cylinder stroke: 8.375 in Cylinder pin diameter: 1.25 in Hinge pin diameter: 1.563 in Blade oscillation: ±4° Float link angle: ±5° Blade/Wing angle range: ±30° blade / ±60° wings Cutting System Main cutting edge: 5/8" x 8" bolt-on steel Wing cutting edge: 1/2" x 7 3/4" AR400 bolt-on Edge design: Reversible hardened steel edges Wear allowance: ~5.5" total edge life Performance & Features Independent hydraulic wing control (each wing moves separately) Free-floating design for uneven surfaces Full down-pressure capability Dual relief valves for impact protection Trip-edge protection on main blade and wings AR400 wear components for high abrasion resistance Designed for pushing, piling, and windrowing snow efficiently Machine Compatibility Recommended loader capacity: 1800+ lbs operating capacity Fits most skid steers and compact track loaders in the mid-size class
