2023 IronCraft 1808

Description

2023 IronCraft 1800 Series 1808 8' Heavy Duty Dual Spindle Pull Cutter (with Chains) Tractor Implement These Heavy-Duty Dual Spindle Cutters are designed for heavy-duty applications such as weeds, grass, and brush up to 3” diameter. These cutters are designed to work with 42 or 52 minimum hp tractors, and are available in 94” and 117” widths. The cutter uses dual spindles with two free-swinging blades each, which reduce the shock of impact when a stationary object is contacted. A slip clutch and dual shock couplers protect the gearboxes and drivelines from damage. Standard equipment includes driveline shields and clutch shields. Front and rear chain discharge shields are available. Available in lift-type and pull-type models. Specs: Product Family: 1800 Series Product: 1808 Description: 8' Heavy Duty Dual Spindle Cutter RPM: 540 or 1000 HP Required: 42 minimum PTO Working Width: 96" Transport Width: 98" Weight (lbs): 1250 lbs Cutting Height: 3-1/2" to 10" Cutting Capacity: 3" Deck Thickness: 10 GA Side Bands: 8" Skid Shoes: Replaceable PTO Drive Shaft: Series 5 w/ slip clutch Center Driveshaft: Shock Coupler Protected Blade Holder: 1/2" Plate Gearbox Rating: 125 HP Outboard Gearbox Rating: 100 HP Wheel Type: Laminated Hub Type: Bearing Hitch Type: Pull Hitch: Cat 1 & 2 Gearbox Warranty: 5 year limited Guarding Options: Chains
