2023 Felling FT30-2LP

Description

FELLING DECKOVER,GN,34'+6',ELEC/HYD,6' H/E RAMP,TB 2023 Felling FT30-2LP Deck-Over Trailer - GN, 34' + 6', Electric/Hydraulic, 6' H/E Ramp, Toolbox Brand: Felling Model: FT30-2LP Year: 2023 Type: Low-profile deck-over equipment trailer Hitch: Gooseneck Deck Length: 34' + 6' beavertail Deck Width: 102" overall GVWR: 37,300 lbs. Payload Capacity: Approximately 30,000 lbs. Trailer Weight: Approximately 8,200 lbs. for 2023 configurations Main Frame: Engineered, fabricated high-tensile steel main beams Crossmembers: Pierced junior I-beam crossmembers Decking: 2" nominal White Oak Beavertail: 6' self-cleaning beavertail Ramps: 6' × 20" heavy-equipment spring-assist ramps Ramp Style: Self-cleaning 5" × 3" angle iron Deck Height: Approximately 33" loaded / 35" unloaded Axles: (2) 15,000-lb. oil-bath axles Axle Spread: 49" Suspension: Hutch spring suspension Brakes: Electric brakes with forward self-adjusting system on all axles Tires: 215/75R17.5 H Wheels: 8-bolt hub-pilot wheels Tie-Downs: 1" straight D-rings Jack: 25,000-lb. 2-speed drop-leg jack Electrical: 7-pole RV plug Lighting: LED lights with sealed wiring harness Safety Chains: 1/2" Grade 70 Toolbox: Lockable toolbox Steps: Two side steps Application: Designed for hauling skid steers, compact track loaders, excavators, tractors and other heavy equipment.
