2023 Kioti CK4020HB

Description

Features KIOTI Diesel Engine High Capacity Hydraulic Pump Power Steering Deluxe Seat Rear PTO Single Lever Joystick Foldable ROPS Simple Maintenance Center Marker High Ground Clearance Illuminated Dashboard 3-Point Control Lever HST Transmission with Twin HST Pedals Engine Engine Model: 3H-TH4A Engine Gross Power: 39.6 hp (29.5 kW) Rated Speed: 2,600 rpm No. of Cylinders: 3 Fuel Type: Diesel Aspiration: Natural Displacement: 111.4 cu. in. (1,826 cc) Fuel Tank Capacity: 9.0 gal. (34 L) Transmission Transmission Type: HST Main Gear: Manual No. of Travel Speeds - Forward / Reverse: Infinite, 3 Range Min. Travel Speed of Forward w/ Ag @ Engine rated speed: 0 mph (0 km/h) Max. Travel Speed of Forward w/ Ag @ Engine rated speed: 14.85 mph (23.91 km/h) Power Take-Off (PTO) PTO Type Trans: Live PTO Power: 33.3 hp (24.8 kW) Rear PTO Speeds (1st): 540 rpm Mid PTO Speeds: 2,000 rpm (Optional) Brakes and Clutch Brakes: Wet Multi Disc Clutch: Dry Single Stage Dimensions w/ AG Tire Length w/ 3-point hitch: 120.9 in. (3,070 mm) Width: 54.5 in. (1,385 mm) Height from Top of ROPS: 92.91 in. (2,520 mm) Wheelbase: 65.7 in. (1,670 mm) Ground Clearance: 13.4 in. (340 mm) Front Tread Ag Tires - Min: 48.2 in (1,225 mm) Rear Tread Ag Tires - Min: 47.6 in. (1,210 mm) Min. Turning Radius w/ Brake: 107.48 in. (2,730 mm) Hydraulics Total Pump Flow: 11.7 gpm (44.4 L/min) 3-Point Hitch Standard Category: Category 1 Lift Capacity, 24" aft of hitch: 1,631 lbs. (740 kg) Control Type: Position Weight Weight w
