2022 Supreme 900T

Description

DEMO UNIT, LIGHTLY USED Minimum Power Requirements: 130 hp / 97 kW Unit Capacity: Struck Capacity: 731 ft³ / 20.7 m³, Capacity with Extension: 841 ft³ / 23.8 m³ Tires: (4) 11R/22.5in 16 Ply Truck Tires With Budd Wheels & HD Axle Empty Weight: 16,259 lbs / 7,375 kg Max Payload: 24,000 lbs / 10,886 kg Dimensions: Height: 117″ / 297 cm, Height w/ 10″ Extension: 127″ / 323 cm, Overall Width: 123″ / 312 cm, Overall Length : 273″ / 693 cm Drive / rpm PTO: (2) Heavy-Duty, Two-Stage Planetary Drives / 540 or 1000 rpm PTO Standard Discharge Ground Clearance: Flat: 30″ / 76 cm, Dogleg: 44″ / 112 cm, Ext. Dogleg: 55″ / 140 cm, 42″ Folding: 53″ / 135 cm, 54″ Folding: 60″ / 152 cm Number of Knives : (10) Replaceable Forage Cutting Blades Conveyor: Front Center Door With 10’ Flat Conveyor Floor Thickness: 3/4” / 19 mm M/S Floor Wall Thickness: 1/4” / 6 mm AR200 Walls Standards Specifications: SS Auger Outer Edge, Two Patented Freestanding Vertical Cutting Augers, Manual Restrictor Plates, Heavy-Duty Tubular Steel Frame, 5/8” / 16 mm AR200 Auger Flighting, Ultra Wear Kicker Plates, Removable Heavy Duty Hitch Jack, 4 pt Scale System, 12 Volt Battery, Independent Steel Oil Reservoirs, SS Conveyor Top Pan
