2022 Bobcat L28

Description

Bobcat L28 Articulated Loader : 24 HP , cab HT , Power Bob-Tach , Radio , Traction Assist . The L28 Bobcat small articulated loader delivers big performance and heavy lifting in a small package. Easily works inside fenced-in landscapes, pens, backyards and more. Impressive lifting capacity and telescoping lift arm and Tight-turning articulation joint . Horsepower 24.8 hp Rated Operating Capacity Straight (ISO) 1534 lb Rated Operating Capacity Art. (ISO) 1222 lb Operating Weight 4195 lb Auxiliary Std Flow 12.1 gal/min Width (over tires) 46.5 in Emissions Tier (EPA) Teir 4 Engine Cooling Liquid Engine Fuel Diesel Horsepower 24.8 hp Turbocharged Engine no ROC with Counterweight Option Straight 1952 lb ROC with Counterweight Option Art. 1475 lb Tipping Load Straight 3068 lb Tipping Load Art. 2444 lb Travel Speed 8.3 mph Fuel Tank 9.6 gal System Relief @ Quick Couplers 2900 psi Auxiliary Std Flow 12.1 gal/min Drive Type Hydrostatic drive with 4 individual drive motors Length 122.4 in Length without Attachment 93.2 in Length with Standard Bucket 122.4 in Width (over tires) 46.5 in Width (with bucket) 50 in Height with Operator Cab 78.1 in Height to Bucket Hinge Pin Ext 104.3 in Height to Bucket Hinge Pin Ret 85.4 in Max Reach 30.9 in Turning Radius Inside 78.2 Turning Radius Outside 100.9 in Wheelbase 47.2 in Articulation Angle 43 degrees Dump Angle @ Maximum Height 40 degrees Ground Clearance 5.5 in Rollback Angle 32 degrees Tire Size 23x 10.5-12, 8ply Wheel Tread 36.4 in
