2014 Gehl RS6-34

Description

No Emissions GENERAL SPECIFICATIONS Approximate Weight (kg) 15,100 lbs. (6850) Length – Less Forks (m) 16’0” (4.9) Width (m) 7’10” (2.4) Ground Clearance (mm) 14” (350) Wheelbase (m) 9’2” (2.8) Turning Radius (m) 12’6” (3.8) Overall Height (m) 7’10” (2.4) Frame Leveling ±10° Fuel Capacity (L) 29 gal. (110) CAPACITIES Lift Capacity (kg) 6,000 lbs. (2722) Maximum Lift Height (m) 34’3” (10.4) Capacity at Maximum Lift Height (kg) 4,000 lbs. (1815) Maximum Forward Reach (m) 23’3” (7.0) Capacity at Max. Forward Reach (kg) 900 lbs. (409) Max. Reach Below Grade (mm) 24” (610) ENGINE Manufacturer John Deere Power (kW) 74 hp (55) Aspiration Turbocharged Model 4045T Interim Tier IV Rated Speed 2400 rpm FEATURES • 6,000 lbs. (2722 kg) Capacity • Boom Control Joystick • Fork Tilt and Frame Level Joystick • 4,000 lbs. Capacity at Full Lift Height • SAHR Parking Brake • Maximum Lift Height - 34 ft. 3 in. • Reverse Warning Horn • 3 Speed Forward/Reverse Powershift Transmission • Brake Lights and Back Up Light • Planetary Axles With an Open Center Differential • Engine Temperature, Fuel, and Hourmeter Gauges • Full Time Four Wheel Drive • Right Hand Side Mounted Rear View Mirror • Four Wheel Wet Disc Brakes • Engine Block Heater • Power Steering • Left Hand Front Fender • Selective Steering (Front Wheel, All Wheel, and Crab) • 12-Volt Electric System • Storage Compartment Under Seat • DYNATTACH® Quick Carriage Release • Dual Element Air Fi
