2025 John Deere PA30

Description

The PA30B Planetary Auger is designed for heavy-duty drilling applications, delivering exceptional torque and durability for skid steers and compact excavators. Ideal for landscaping, construction, and utility work, this attachment ensures efficient performance in challenging soil conditions. - - Key Features - Heavy Duty, All Gear Design - Sealed Drive Unit - Reverse Rotation Feature - - Specification: - Weight (without mounting bracket): 138 lbs - Motor Displacement: 240 cc/rev (14.9 cu. in./rev.) - Minimum Hydraulic Flow: 57 L/min. (15 gpm) - Maximum Hydraulic Flow: 114 L/min. (30 gpm) - Maximum Operating Pressure: 24 100 kPa (3,500 psi) - Planetary Gear Ratio: 4.4:1 - Planetary Maximum Torque Rating: 6100 Nm (4,500 ft.-lb.) - Output Shaft: 51-mm (2 in.) hexagon - Output Torque: 4130 Nm (3,044 ft.-lb.) - Maximum Auger Bit Diameter: 910 mm (36 in.) - Overall Auger Bit Length: 1220 mm (48 in.) - - Compatability: 316GR, 318G, 320G, 324G, 330G, and 330 P-Tier SSLs; 317G, 325G, 331G, 331 P-Tier, 333G, and 333 P-Tier CTLs; 50 P-Tier and 60 P-Tier CEXs; 184 G-Tier*, 204 G-Tier*, 244 P-Tier*, 304 G-Tier*, and 324 P-Tier* CWLs. - *Requires skid-steer-style Quik-Tatch coupler for operation. - - If you have any concerns about the compatibility of this attachment, please reach out to your local RDO Equipment location. Fits On (Machine Category): Skid Steer Loaders, Attachment Type: Auger
