2023 Kubota L3902

Description

From its beginnings as the L Series in 1967, to its evolution as the Standard L Series in 1997, Kubota’s popular compact tractor line has continued to build on its reputation for affordability, durability and versatility. Enhanced and refined over generations of models, The Standard L Series has earned its rightful position as the core of the Kubota compact tractor lineup and the top selling compact tractor in North America for more than 10 years*. Engine Model: L3902 HST 4WD Type: Direct Injection, Vertical, Water-Cooled 4 Cycle Diesel Engine Gross Power: 37.5 HP (28.0 kW) Engine Net Power: 36.3 HP (27.1 kW) PTO Power: 30.3 HP (22.6 kW) No. of Cylinders: 3 Bore and Stroke: 3.4 x 4.0 in. (87 x 102.4 mm) Total Displacement: 111.4 cu. in. (1826 cc) Rated Speed: 2700 RPM Battery: 12V, RC: 120 min, CCA: 600 A Alternator: 12V, 45A Fuel Tank Capacity: 11.1 gal. (42 L) PTO Rear PTO: Live independent PTO with hydraulic clutch PTO / Engine Speed: 540/2470 RPM Hydraulic Lift Control Type: Position Control Pump Capacity (Main): 6.8 gpm. (25.7 l/min.) Pump Capacity (PS): 4.1 gpm. (15.6 l/min.) 3 - Point Hitch: SAE Category I Lift Capacity at Lift Points: 1985 lb. (900 kg.) Lift Capacity at 24" behind LP: 1433 lb. (650 kg.) System Pressure: 165 kgf/cm2 (16.2 MPa) Traveling System Transmission: Hydrostatic transmission, 3 range speed Steering: Integral type power steering Brake: Mechanical, Wet Disc Type Clutch: No Clutch Tire Size AG Standard: (Front): 7.0 - 16; (Rear): 11.2 - 24 TURF Opt
