2023 Kubota SVL97-2HC

Description

CTL-A/C Cab/Heat-Hyd QC-Camera-18" Track-Bucket 2023 Kubota SVL97-2HC Compact Track Loader – Enclosed Cab – A/C & Heat – Hydraulic Quick Coupler – Rear Camera – 18" Tracks – Bucket Specs General Category: Compact Track Loader Model: SVL97-2HC Year: 2023 Operator Station: Enclosed ROPS/FOPS cab with heat and air conditioning Lift Path: Vertical Lift Quick Coupler: Hydraulic Quick Attach Rear View Camera: Factory backup camera Bucket: General-purpose bucket included Track Width: 17.7 in. (commonly referred to as 18" tracks) Operating Weight: Approximately 11,574 lbs. (closed cab) Engine Engine Manufacturer: Kubota Engine Model: V3800-TIEF4 Engine Type: Turbocharged 4-cylinder Tier 4 Final diesel Gross Horsepower: 96.4 HP Net Horsepower: 87.0 HP Displacement: 230 cu. in. (3.8 L) Rated Engine Speed: 2,400 RPM Fuel Tank Capacity: 29.3 gal. DEF Tank Capacity: 3.4 gal. Performance Rated Operating Capacity (35%): 3,200 lbs. Tipping Load: 9,143 lbs. Bucket Breakout Force: 7,961 lbs. Lift Arm Breakout Force: 6,742 lbs. Travel Speed: 5.0 mph (low) / 7.3 mph (high) Ground Pressure: Approximately 4.5 psi Traction Force: 12,178 lbs. Hydraulic System Standard Auxiliary Hydraulic Flow: 23.1 GPM High-Flow Auxiliary Hydraulics: 40.0 GPM Auxiliary Hydraulic Pressure: 3,553 PSI Hydraulic Quick Coupler: Factory installed Hydraulic Tank Capacity: 10.1 gal. Undercarriage Track Width: 17.7 in. (450 mm) Track Rollers: 5 per side Track Ground Contact Length: 65.6 in. Ground Clearance: 11.5 in. Rubber
