2014 Bobcat S570

Description

Bobcat S570 Skid Steer Loader : 61 HP , Cab HT / AC , Power Bob-Tach , 2 SPD , Radio SPECS: Engine Aspiration - Turbocharged Cooling system - Liquid Emission Tier Level - Tier 4 Fuel Type - Turbo Diesel Gross Power - 61 hp (45 kw) Hydraulic System Main pump high flow optional - 26.7 gal/min (98 l/min) Main pump flow standard - 17.1 gal/min (64 l/min) Relief Valve Pressure - 3500 psi Loader Bucket Width - 68 in (173 cm) Height to hinge pin - 10 ft (3 m) Loader Series - M2-Series Operating Load Rating - 1950 lbs (885 kg) Operating Width - 64.7 in (163 cm) Tipping Angle - 3900° Operating Specifications Fuel Capacity - 24.7 gal (91 l) Lift Arm Path - Vertical Max Speed - 7.4 mph (11 kph) Operational Weight - 6479.4 lbs (2,939 kg) Dimensions Clearance at Max Lift and Dump - 7.7 ft (2 m) Ground Clearance - 7.3 in (18 cm) Height - Top of Cab - 6.5 ft (2 m) Length w/o Bucket - 8.8 ft (2 m) Length with Bucket - 11.1 ft (3 m) Reach at Max Lift and Dump - 32.6 in (81 cm) Wheelbase - 3.6 ft (1 m) Width Over Tires - 5.4 ft (2 m)
